Domino Gx150i User Manual

# Description # Description
A RS232 G Print Head 4
B Encoder 1 H Power Supply Input
C Encoder 2 I Ethernet
D Print Head 1 J USB
E Print Head 2 K I/O Terminal Block 1
F Print Head 3 L I/O Terminal Block 2
CONNECTOR LAYOUTS
WARNING Electricity. Risk of injury.
Turn o the equipment and disconnect the power supply before
disconnecting or making electrical connections.
When powered on, the controller contains live electrical components.
Physical contact with live electrical components can result in an electric
shock.
CAUTION Electricity. Risk of damage to equipment.
Turn o the equipment and disconnect the power supply before
disconnecting or making electrical connections.
When powered on, the equipment contains live electrical components.
An incorrect electrical connection can damage the equipment.
INSTALLATION
35 EPT053091 - Issue 5 - 07 May 2021
