Export Audit Log
To export the audit log:
1.
Insert a USB memory device into one of the controller's USB sockets.
Note
FAT32
2.
Select Home > Setup > Diagnostics.
3. Select the Audit log export icon:
4.
Select the Path dialog box and open the USB folder.
1.Notes "sda1" and "sdb1" are the top level partitions of USB memory devices that
are connected to the controller.
2. "sda1" is the first USB memory device that was connected. "sdb1" is the
second USB memory device that was connected.
5.
Select a folder on the USB memory device and select Select.
6. Select Export.
End of procedure.
LABEL CREATOR
Create New Label
To create a new label:
1. Select Home > Label manager.
2. Select Create new label.
3. Select the Label name text box.
4. Use the on screen keyboard, to enter a name that the label will be saved as.
5. Select the green Tick icon.
6. Select Layout settings and choose a print group that the label will be designed for.
7. Select Create label.
End of procedure.
Label Settings
Each individual label design can be created and saved with its own custom print settings. The
default values for these settings is defined on the Label defaults screen, see Label Defaults on
page 101.
To set the label's print settings:
1.
In the label creator's side menu select the Label tab.
2.
The layout settings described in the table below can now be edited.
Note
Some settings have a tick box to lock the setting and prevent accidental
changes. To change a setting, deselect the tick box.
OPERATION
EPT053091 - Issue 5 - 07 May 2021 134
