Domino Macrojet 2 User Manual

INSTALLATION
20509 Issue 7 Jan 2018 A-5
Print Heads
12mm, 16mm, 20mm: Y=223
12mm Low: Y=273
32mm, 50mm: Y=269
Print Heads
12mm, 16mm, 20mm: X=85
32mm, 50mm: X=111
Y
X
394
70
25
613 min
448
226
16
Min. bend
radius = 150
295
Ink
Container
2m Ink Feed
Pipe
Centre Line of First Nozzle
12mm, 16mm, 20mm: H=27.5mm
12mm Low: H=5mm
32mm: H=32mm, 
50mm: H=22.5mm
(All dimensions nominal)
200
145
33.8
24.5
H
50
380
380
40
4 Bolts
Z ADJ
25
min.
15mm
shaft
450
Print Heads
12mm, 16mm, 20mm: Z=130
32mm, 50mm: Z=175
Assumed top of
conveyor
70
Installation Diagram
TP7005_2
Note: (a) Dimmensions in mm 
(b)Mounting frame is optional
