Operation
Pre-Use Checklist
WARNING !
Any use of the ventilator requires full under-
standing and strict observation of all portions
of these Operating Instructions.
Operation
Pre-Use Che
cklist
Operating Instructions Oxylog 2000, SW 3.n
28
Check before start-up
OK?
Either cylinder pressure equals at least 1500 psi or
ventilator connected to medical gas pipeline system 0
Power supply verified: fully charged pack of rechargeable (NiCd) or
new alkaline batteries
If external power supply: either connected to line power or
to on-board power supply 0
All tubing connected 0
Function check
Connect test lung to patient valve 0
Dial knobs: VT to 0.5 L
Rate to 12 bpm
I:E to 1: 2
Pmax to 60 cmH2O
PEEP to 5 cmH2O
Switch for ventilation modes set to CMV
ON/OFF switch to I:
Display:
Red alarm status lights up briefly
Alarm tone sounds twice
Green LED lights up with external power supply
After approx. 6 seconds
Display:
0
Oxylog 2000 ventilates the test lung
Test "Paw low" alarm: Remove test lung alarm after approx. 20 seconds
Test "Paw high" alarm: Re-attach test lung and compress alarm
For error messages, see "Troubleshooting", page 45 in these Operating Instructions
Functional check completed successfully
Self test
SW-version xx.xx
Self test OK
