Operation
Using CMV
Operating Instructions Oxylog 2000, SW 3.n
29
"Care", page 40
"Preparation", page 14
"Checks of Readiness for Operation", page 23
Using CMV
CMV = Controlled Mandatory Ventilation
For ventilator rates of 5 to 40 bpm.
NOTE: The Oxylog 2000 ventilator limits the minimum
ventilator rate to 5 bpm during CMV.
1 Set switch for ventilator modes to CMV
NOTE: For quick pre-setting you may set knobs »Rate«
and »VT« to matching colors on dial scale. This will
adjust ventilation parameters to settings for infant,
pediatric, and adult patients, respectively.
2 Set »Rate« and »VT« knobs.
Body weight Rate VT
(kg) (bpm) (L)
Green range: 30 to 40 0.1 to 0.3
infants
(7.5 to 20)
Blue range: 20 to 30 0.3 to 0.8
children
(20 to 40)
Brown range: 5 to 20 0.8 to 1.5
adults
(over 40)
WARNING !
Always use ventilator that has been cleaned
and disinfected and has been successfully
tested to be ready for operation.
22
1
00129033
