Technical Data
Operating Data
Operating Instructions Oxylog 2000, SW 3.n
54
Operating Data
Gas supply
Supply gas Oxygen for medical use, mixture of gases,
medical air in emergencies
Quality of the supply gas
Supply From a pipeline system
or
from medical gas cylinders
Supply pressure 40 to 88 psi ( 2.7 to 6.0 bar) at 80 L/min
Gas cylinders and pressure regulators
Pressure regulators must have a safety relief valve on the output side to limit
output pressure to approx. 74 psi (5 bar) in the event of a defect.
Connection DISS O2 (male),
may also be used for medical air in an emergency
Gas consumption for internal control Approximately 1.0 L/min
with »Air Mix« selected Approximately 50 % of the effective minute ventilation
with »No Air Mix« selected Approximately 100 % of the effective minute ventilation
Typical time of operation
at a minute ventilation of 10 L/min
D-type O2 cylinder Approximately 32 minutes without mixing (No Air Mix)
Approximately 64 minutes with mixing (Air Mix)
E-type O2 cylinder Approximately 56 minutes without mixing (No Air Mix)
Approximately 112 minutes with mixing (Air Mix)
Electrical supply
Input voltage for Oxylog 2000 12 V ±1 V DC
Connection for
external power supply
12 V / 24 V / 28 V DC with DC/DC converter
WARNING !
Always use medical grade oxygen or air that is
dry and free from dust and oil. Contaminated
gas may cause ventilator malfunction.
WARNING !
Always use gas cylinders and pressure
regulators that are officially approved and
comply with all applicable safety regulations.
