Monitoring
70
Instructions for Use Oxylog 3000 SW 1.n
Displaying curves
The main page displays the airway pressure curve
Paw (t) or flow curve Flow (t).
To display a different curve:
z Press curves key.
Refer to the "Operating concept" section on
page 19 for additional information.
Displaying other measured values
Additional measured values are displayed in the
measured values window.
Refer to the "Operating concept" section on
page 19 for additional information.
To switch between the values:
z Press the Values key: the next value is
displayed on the screen.
The following pairs of values are displayed in the
default setting. Refer to "Abbreviations"
on page 16. These options are:
–MV
, O2
–f, VTe
– PEEP, Pmean
– Ppeak
, Pplat
–MVspn
, fspn
The pairs of values can be configured as required.
See customer service mode.
