Emerson Bettis 500 User Manual

Installation and Operation Manual
E2K-405-0218 Rev. 2 February 2018
11
Section 3: Installation
Installation
3.3 Electrical Connections
3.3.1 Remove Separate Terminal Chamber (STC) Cover
WARNING: BEWARE OF MULTIPLE POWER SOURCES
Verify power is disconnected before removing STC Cover.
Multiple power sources may exist under the cover.
NOTE:
Valve actuator requires a circuit breaker within the line of sight, sized for the
motor currently specied on the nameplate.
See Appendix Section A.7, for the circuit breaker options.
Remove cover with a strap wrench, drift, or pinch bar by rotating the
cover counterclockwise.
Figure 3-2 Removal of STC Cover
TEC2000/TEC2 Enclosure
Model 500 Enclosure

Emerson Bettis 500 Specifications

General

Brand	Emerson
Model	Bettis 500
Category	Controller
Language	English
