Installation and Operation Manual
E2K
-405-0218 Rev
. 2
26
Section 3: Installation
Installation
3.8.1
24 Vdc Po
wer Source
If the RDM is to rece
ive powe
r from the actuator
, connec
t cable type Belden 8723
or equivalen
t as detailed in
T
able 3-3
. The cable distance is limited to 1,200 fee
t
(366 mete
rs).
NOTE:
By using two cables, Belde
n 8719, or equivalent f
or powe
r and Belden 9841 or
equivalen
t for RS
-485 comm
unication, the distance limitation is incre
ased to
4,000 fee
t (1,200 meters).
Figure 3-21
RDM Interface Module (Suppor
t Both 24V DC and A
C)
P2
SW1 1-6
33
35
