NOTE:
Host Control means the control of this relay has been given to the network if a
Controlinc card has been installed. The relay will not function if the Controlinc card
is not installed. Flashing means the output will cycle ON and OFF in one-second
intervals while the function is active.
Table 5-2. Relay Output Function List
• LSO (Open limit) • LOW BATTERY • VALVE STALL • LOCAL ESD
• LSC (Close limit) • LOCAL
• VALVE DRIFT
(MOVED BY
HANDWHEEL)
• ESD ACTIVE
• LSA (Intermediate limit A) • STOP (SS OFF) • LOST POWER • LOST ANALOG
• LSB (Intermediate limit B) • REMOTE
• MOTOR
OVERLOAD
• ACTUATOR FAIL
• OPENING • OPEN TORQUE • LOST PHASE
• HOST CONTROL
(Controlled by
Network)
• CLOSING • CLOSE TORQUE • OPEN INHIBIT
• LOST COM
A/B
• MOVING
• OVER TORQUE
(Open or Close)
• CLOSE INHIBIT • UNIT ALARM
• Partial Stroke
Test (PST)*
*Only available for Relays 3 and 4.
