Emerson Digitax ST User Manual

Safety
Information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
Basic
parameters
Running the
motor
Optimization
EtherCAT
interface
SMARTCARD
Operation
Onboard
PLC
Advanced
parameters
Technical
Data
Diagnostics
UL listing
information
146 Digitax ST User Guide
Issue Number: 5
12.11 Menu 11: General drive set-up
* Modes 1 and 2 are not user saved, Modes 0, 3 and 4 are user saved
Parameter
Range(
Ú) Default(Ö)
Type
11.01 Parameter 0.11 set up
Pr 1.00 to Pr 21.51
Pr 3.29 RW Uni PT US
11.02 Parameter 0.12 set up Pr 4.01 RW Uni PT US
11.03 Parameter 0.13 set up Pr 7.07 RW Uni PT US
11.04 Parameter 0.14 set up Pr 4.11 RW Uni PT US
11.05 Parameter 0.15 set up Pr 2.04 RW Uni PT US
11.06 Parameter 0.16 set up Pr 2.02 RW Uni PT US
11.07 Parameter 0.17 set up Pr 4.12 RW Uni PT US
11.08 Parameter 0.18 set up Pr 8.29 RW Uni PT US
11.09 Parameter 0.19 set up Pr 7.11 RW Uni PT US
11.10 Parameter 0.20 set up Pr 7.14 RW Uni PT US
11.11 Parameter 0.21 set up Pr 7.15 RW Uni PT US
11.12 Parameter 0.22 set up Pr 1.10 RW Uni PT US
11.13 Parameter 0.23 set up Pr 1.05 RW Uni PT US
11.14 Parameter 0.24 set up Pr 1.21 RW Uni PT US
11.15 Parameter 0.25 set up Pr 1.22 RW Uni PT US
11.16 Parameter 0.26 set up Pr 3.08 RW Uni PT US
11.17 Parameter 0.27 set up Pr 3.34 RW Uni PT US
11.18 Parameter 0.28 set up Pr 6.13 RW Uni PT US
11.19 Parameter 0.29 set up Pr 11.36 RW Uni PT US
11.20 Parameter 0.30 set up
Pr 11
.42 RW Uni PT US
11.21 Parameter scaling 0.000 to 9.999 1.000 RW Uni US
11.22 Parameter displayed at power-up Pr 0.00 to 00.50 Pr 0.10 RW Uni PT US
11.23 Serial address {0.37}0 to 247 1RWUniUS
11.24 Serial mode {0.35} AnSI (0), rtU (1), Lcd (2) rtU (1) RW Txt PT US
11.25 Baud rate {0.36}
300 (0), 600 (1), 1200 (2), 2400 (3), 4800 (4),
9600 (5), 19200 (6), 38400 (7),
57600 (8)*, 115200 (9)* *Modbus RTU only
19200 (6) RW Txt US
11.26 Minimum comms transmit delay 0 to 250ms 2 RW Uni US
11.28 Drive derivative 0 to 16
RO Uni NC PT
11.29 Software version {0.50} 1.00 to 99.99
RO Uni NC PT
11.30 User security code {0.34}0 to 999 0RWUniNCPTPS
11.32 Maximum current rating {0.32} 0.00 to 9999.99 A
RO Uni NC PT
11.33 Drive voltage rating {0.31} 200 (0), 400 (1), 575 (2), 690 (3)
RO Txt NC PT
11.34 Software sub-version 0 to 99
RO Uni NC PT
11.35 Number of modules 0 to 10 0 RW Uni PT US
11.36
SMARTCARD parameter
data previously loaded
{0.29}0 to 999 0ROUniNCPTUS
11.37 SMARTCARD data number 0 to 1003 0 RW Uni NC
11.38 SMARTCARD data type / mode 0 to 18
RO Txt NC PT
11.39 SMARTCARD data version 0 to 9,999 0 RW Uni NC
11.40 SMARTCARD data checksum 0 to 65,335
RO Uni NC PT
11.41 Status mode timeout 0 to 250s 240 RW Uni US
11.42 Parameter copying {0.30}
nonE (0), rEAd (1), Prog (2), AutO (3),
boot (4)
nonE (0) RW Txt NC *
11.43 Load defaults nonE (0), Eur (1), USA (2) nonE (0) RW Txt NC
11.44 Security status {0.49} L1 (0), L2 (1), Loc (2)
RW Txt PT US
11.45 Select motor 2 parameters OFF (0) or On (1) OFF (0) RW Bit US
11.46 Defaults previously loaded 0 to 2000
RO Uni NC PT US
11.47 Drive Onboard PLC program enable
Halt program (0)
Run program: out of range = clip (1)
Run program: out of range = trip (2)
Run program: out of range = trip (2) RW Uni US
11.48 Drive Onboard PLC program status -128 to +127
RO Bi NC PT
11.49
Drive Onboard PLC programming
events
0 to 65,535
RO Uni NC PT PS
11.50
Drive Onboard PLC program average
scan time
0 to 65,535 ms
RO Uni NC PT
11.51 Drive Onboard PLC program first run OFF (0) or On (1)
RO Bit NC PT
11.52
Drive serial number least significant 9
digits
0 to 999999999
RO Uni NC PT
11.53
Drive serial number most significant
digits
0 to 65535
RO Uni NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
