15.5 DC Supplied drive
The drive can also have DC feed for UL applications as follows: -
Supply connected to -DC and +DC terminals.
Table 15-3 DC fusing
In the table above, Ferraz xx may be 00 (fuse with no trip indicator installed) or 21 (fuse installed with trip indicator).
15.6 UL listed accessories
Model
Volts DC
nominal
Fuse current
rating
R/C JFHR2 fuse manufacturer, type, Amps
DST1201 340 25 Ferraz, 6,9xx CP GRC, 25 Siba URZ14x51 gR 690, 25
DST1202 340 32 Ferraz, 6,9xx CP GRC, 32 Siba URZ14x51 gR 690, 40
DST1203 340 40 Ferraz, 6,9xx CP GRC, 40 Siba URZ14x51 gR 690, 40
DST1204 340 50 Ferraz, 6,9xx CP GRC, 50 Siba URZ14x51 gR 690, 50
DST1401 680 25 Ferraz, 6,9xx CP GRC, 25 Siba URZ14x51 gR 690, 25
DST1402 680 25 Ferraz, 6,9xx CP GRC, 25 Siba URZ14x51 gR 690, 25
DST1403 680 25 Ferraz, 6,9xx CP GRC, 25 Siba URZ14x51 gR 690, 25
DST1404 680 25 Ferraz, 6,9xx CP GRC, 25 Siba URZ14x51 gR 690, 25
DST1405 680 25 Ferraz, 6,9xx CP GRC, 25 Siba URZ14x51 gR 690, 25
NOTE
• Digitax ST Keypad • SM-PROFIBUS-DP-V1
• Digitax ST Braking resistor • SM-DeviceNet
• SM-Keypad Plus • SM-I/O Timer
• SM-I/O Plus • SM-CAN
• SM-Ethernet • SM-INTERBUS
• SM-CANopen • SM-Applications Lite
• SM-Universal Encoder Plus • SM-Applications Lite V2
• SM-Resolver • SM-SLM
• SM-Encoder Plus • SM-Applications
• SM-I/O Lite • SM-I/O PELV
• SM-I/O 120V • SM-I/O 24V Protected
• SM-LON • SM-I/O 32
• SM-Applications Plus • SM-SERCOS
• 15-way D-type converter • SM-I/O Timer
• SM-Encoder Output Plus • SM-EtherCAT
•SM-LON
