Digitax ST User Guide 199
Issue: 5
Drive cooling fan
The drive cooling fan is controlled by the temperature from monitoring
points and other actions as follows:
If the "hot" alarm is active or the IGBT temperature (Pr 7.34) is greater
than the upper threshold then the fan will run at full speed. It will continue
to run at full speed until the IGBT temperature is below the lower
threshold. See the table below for the upper and lower thresholds.
If a Solutions Module indicates that it is too hot the fan runs at full speed.
The fan will continue to run at full speed for 10 seconds after the
Solutions Module has cooled down.
The fan can still be forced to run at full speed at all times if Pr 6.45 is set
to one. The fan will continue to run at full speed for 10 seconds after
Pr 6.45 has been set to zero.
For all other conditions the fan runs at low speed.
14.3 Status indications
Table 14-5 Status indications
Table 14-6 Solutions Module and SMARTCARD status indications
at power-up
14.4 EtherCAT Diagnostics
14.4.1 EtherCAT interface ID code
Table 14-7 EtherCAT interface ID code
This parameter is useful for checking the The EtherCAT interface is of
the correct type.
14.4.2 EtherCAT interface firmware version
Table 14-8 EtherCAT interface firmware version - (major and
minor)
Table 14-9 EtherCAT interface firmware version - (subversion)
The software version of the EtherCAT interface can be identified by
looking at Pr 17.02 and Pr 17.51.
The software version takes the form of xx.yy.zz, where Pr 17.02 displays
xx.yy and Pr 17.51 displays zz, for software version 01.01.00, Pr 17.02
will display 1.01 and Pr 17.51 will display 0.
The full version of the EtherCAT interface firmware can be assembled by
combining the major version (xx.yy) and the minor version (zz) as
follows: xx.yy.zz.
Model Upper threshold Lower threshold
DST1201 to DST1204
DST1401 to DST1404
120 ºC 75 ºC
DST1405 145 ºC 90 ºC
Upper
display
Description
Drive output
stage
ACUU AC Supply loss
Enabled
The drive has detected that the AC supply has been
lost and is attempting to maintain the DC bus voltage
by decelerating the motor.
dc DC applied to the motor
Enabled
The drive is applying DC injection braking.
dEC Decelerating
Enabled
The drive is decelerating the motor.
inh
Inhibit
Disabled
The drive is inhibited and cannot be run.
The drive enable signal is not applied to terminal 31 or
Pr 6.15 is set to 0.
POS Positioning
Enabled
The drive is positioning/orientating the motor shaft.
rdY Ready
Disabled
The drive is ready to be run.
run
Running
Enabled
The drive is running.
SCAn Scanning
Enabled
Regen> The drive is enabled and is synchronising to
the line.
StoP Stop or holding zero speed
Enabled
The drive is holding zero speed.Regen> The drive is
enabled but the AC voltage is too low, or the DC bus
voltage is still rising or falling.
triP Trip condition
Disabled
The drive has tripped and is no longer controlling the
motor. The trip code appears on the lower display.
Lower
display
Description
boot
A parameter set is being transferred from the SMARTCARD to the
drive during power-up. For further information, refer to the User Guide.
cArd
The drive is writing a parameter set to the SMARTCARD during power-
up.
For further information, refer to the User Guide.
loAding
The drive is writing information to a Solutions Module.
EtherCAT interface ID code
Pr 17.01
Default 421 (EtherCAT)
Range -
Access RO
EtherCAT interface firmware version - (major and minor) (xx.yy)
Pr 17.02
Default N/A
Range 00.00 to 99.99
Access RO
EtherCAT interface firmware version (subversion) (zz)
Pr 17.51
Default N/A
Range 0 to 99
Access RO
