Safety
Information
Product
information
Mechanical
Installation
Electrical
installation
Getting
started
Basic
parameters
Running the
motor
Optimization
SMARTCARD
operation
Onboard
PLC
Advanced
parameters
Technical
data
Diagnostics
UL
information
118 Mentor MP User Guide
www.controltechniques.com Issue: 3
Figure 11-11 Menu 8 logic diagram (cont)
Destination
Any
bit
parameter
I/O
state
Start Key
5V (On)
Destination
Any
bit
parameter
I/O
state
Reverse Key
5V (On)
Toggle enable
Pr
8.52
8.27
Relay
source
Relay source
invert
Any
bit
parameter
x(-1)
Relay
state
Drive
Healthy
8.60
Relay
source
Relay source
invert
Any
bit
parameter
x(-1)
Relay
state
Contactor
enable
Relay 1
Relay 2
