Mentor MP User Guide 43
Issue: 3 www.controltechniques.com
Table 4-14 Ferraz Shawmut branch circuit protection fusing for size 2 drives
USA fuses are only rated up to 600Vac.
Table 4-15 Ferraz Shawmut DC protection fusing for size 2 drives
The use of the A100P series fuses is limited to applications with L/R time constants of 30ms or less.
DC fusing is only required on four quadrant (R) drives.
4.6.2 Alternative fusing
Please refer to section 12.2.2 Alternative fusing on page 157.
Model
International USA
Description Catalogue number Ref number Description Catalogue number Ref number
Auxiliary
25A 600Vac
High Speed
Class J
HSJ205 G235871J
25A 600Vac
High Speed
Class J
AJT25R X21160J
MP350A4(R)
MP350A5(R)
MP350A6(R)
General
purpose IEC
(square body)
NH2GG69V355 Y228503
General purpose
US (round body)
A6D400R B216776
MP420A4(R) NH3GG69V400 D228508 A6D500R P217294
MP470A5(R)
MP470A6(R)
NH4GG69V630-8
NH4AGG69V630-8
E215537
W222107
A6D600R T217804
MP550A4 (R)
NH4GG69V630-8
NH4AGG69V630-8
E215537
W222107
MP700A4(R)
MP700A5(R)
MP700A6(R)
NH4GG69V800-8
NH4AGG69V800-8
K216554
M222858
A4BQ800 Z219373
MP825A4(R)
MP825A5(R)
MP825A6(R)
NH4GG69V800-8
NH4AGG69V800-8
K216554
M222858
MP900A4R)
General
purpose IEC
(round body)
MF76GG69V1250 E302753
A4BQ1000 P216282
MP1200A4(R)
MP1200A5(R)
MP1200A6(R)
A4BQ1200 R216790
MP1850A4(R)
MP1850A5(R)
MP1850A6(R)
MF114GG69V2000 G302755 A4BQ2000 B223101
NOTE
Model
International USA
Description Catalogue number Ref number Description
Catalogue
number
Ref number
MP350A4R
Square Body fuse
D123GB75V630TF C098557
American round fuse
A70QS600-4 Y219993
MP350A5R
MP350A6R
A100P600-4 A217373
MP420A4R D123GB75V800TF J220946 A70QS800-4 Z213830
MP470A5R
MP470A6R
D2122GD75V900TF T220955
American round fuses
2 in parallel
A100P1000-4 (x2) Y217371 (x2)
MP550A4R A70QS450-4 (x2) F214848 (x2)
MP700A4R
D2123GB75V12CTF D098558
A70QS600-4 (x2) Y219993 (x2)
MP700A5R
MP700A6R
American round fuse A100P1200-4 N218397
MP825A4R
American round fuses
2 in parallel
A70QS800-4 (x2) Z213830 (x2)
MP825A5R
MP825A6R
American round fuse A100P1200-4 N218397
MP900A4R D2123GB75V14CTF B090483
American round fuses
3 in parallel
A70QS600-4 (x3) Y219993 (x3)
MP1200A4R
Square Body fuses
3 in parallel
PC73UD13C630TF
(x3)
Q300509 (x3)
American round fuses
3 in parallel
A70QS700-4 (x3) E202772 (x3)
MP1200A5R
MP1200A6R
A100P700-4 (x3) T223163 (x3)
MP1850A4R
Square Body fuses
4 in parallel
PC73UD13C700TF
(x4)
R300510 (x4)
American round fuses
5 in parallel
A70QS600-4 (x5) Y219993 (x5)
MP1850A5R
MP1850A6R
A100P600-4 (x5) A217373 (x5)
NOTE
