Emerson MP75A4 User Manual

Safety
Information
Product
information
Mechanical
Installation
Electrical
installation
Getting
started
Basic
parameters
Running the
motor
Optimization
SMARTCARD
operation
Onboard
PLC
Advanced
parameters
Technical
data
Diagnostics
UL
information
16 Mentor MP User Guide
www.controltechniques.com Issue: 3
Figure 3-4 Removal and installation of a keypad
To fit, align the MP-Keypad and press gently in the direction shown until
it clicks into position (A).
To remove, while pressing the tabs inwards (B), gently lift the MP-
Keypad in the direction indicated (C).
The keypad can be installed / removed while the drive is powered up and
running a motor, providing that the drive is not operating in keypad
mode.
B
B
C
A
NOTE
