Emerson MP75A4 User Manual

Safety
Information
Product
information
Mechanical
Installation
Electrical
installation
Getting
started
Basic
parameters
Running the
motor
Optimization
SMARTCARD
operation
Onboard
PLC
Advanced
parameters
Technical
data
Diagnostics
UL
information
Mentor MP User Guide 29
Issue: 3 www.controltechniques.com
Figure 3-20 Location of the power and ground terminals on size 2A and 2B drives
5mm
Machine
feedback
terminals
Ta ch o
connections
5mm
Auxiliary
connections
Control and
encoder
connections
2.5 mm
Relay
connections
3.5mm
3.5 mm
T25 Torx
Ground
connections
M12 nut 19
mm AF
DC output
Size 2A:
Size 2B:
M10 nut 17
mm AF
AC input
M12 nut 19mm AF
Size 2A:
Size 2B:
M10 nut 17mm AF

Emerson MP75A4 Specifications

General

Brand	Emerson
Model	MP75A4
Category	DC Drives
Language	English
