12.2.2 Alternative fusing
Cooper Bussmann or Siba fuses are an acceptable alternative.
Table 12-22 Cooper Bussmann semiconductor fusing for size 1 two quadrant drives
Table 12-23 Cooper Bussmann North American alternative semiconductor fusing for size 1 two quadrant 480V drives only
Table 12-24 Cooper Bussmann North American alternative semiconductor fusing for size 1 two quadrant 480V and 575V drives
Table 12-25 Cooper Bussmann North American alternative semiconductor fusing for size 1 two and four quadrant drives
Table 12-26 Cooper Bussmann branch circuit protection fusing for 480V and 575V size 1 drives
Model Fuse type
Rating
V
Rating
A
Catalogue number
Auxiliary 10.3 x 38mm ferrule 600Vac 12 FWC-12A10F
MP25A4 MP25A5 ET Type BS88 fuse
690Vac
40 40ET
MP45A4 MP45A5 FE Type BS88 fuse 80 80FE
MP75A4 MP75A5 EET Type BS88 fuse 140 140EET
MP105A4 MP105A5 FEE Type BS88 fuse 160 160FEE
MP155A4 MP155A5 FM Type BS88 fuse 250 250FM
MP210A4 MP210A5 FMM Type BS88 fuse 400 400FMM
Model Fuse type
Rating
V
Rating
A
Catalogue number
MP25A4
FWH series American round fuse 500Vac
40 FWH-40
MP45A4 70 FWH-70
MP75A4 125 FWH-125
MP105A4 175 FWH-175
MP155A4 250 FWH-250
MP210A4 350 FWH-350
Model Fuse type
Rating
V
Rating
A
Catalogue number
MP25A4 MP25A5
FWP series American round fuse 700Vac
40 FWP-40
MP45A4 MP45A5 70 FWP-70
MP75A4 MP75A5 125 FWP-125
MP105A4 MP105A5 175 FWP-175
MP155A4 MP155A5 250 FWP-250
MP210A4 MP210A5 300 FWP-300
Model Fuse type
Rating
V
Rating
A
Catalogue number
MP25A4(R) MP25A5(R)
FWJ series American round fuse 1000Vac
40 FWJ-40
MP45A4(R) MP45A5(R) 70 FWJ-70
MP75A4(R) MP75A5(R) 125 FWJ-125
MP105A4(R) MP105A5(R) 175 FWJ-175
MP155A4(R) MP155A5(R) 250 FWJ-250
MP210A4(R) MP210A5(R) 350 FWJ-350
Model Fuse type
Rating
V
Rating
A
Catalogue number
Auxiliary 10.3 x 38mm ferrule
600Vac
12 LP-CC-12
MP25A4(R) MP25A5(R)
26.9 x 60.5mm ferrule
30 LPJ-30SP
MP45A4(R) MP45A5(R) 60 LPJ-60SP
MP75A4(R) MP75A5(R)
Cylindrical bolt-in type fuse
80 LPJ-80SP
MP105A4(R) MP105A5(R) 110 LPJ-110SP
MP155A4(R) MP155A5(R) 175 LPJ-175SP
MP210A4(R) MP210A5(R) 225 LPJ-225SP
