174 Mentor MP User Guide
www.controltechniques.com Issue: 3
Table 13-2 Serial communications look-up table
13.3 Trip categories
Trips can be grouped into the following categories. It should be noted that a trip can only occur when the drive is not tripped or is already tripped but
with a trip with a lower priority number.
Table 13-3 Trip categories
Unless otherwise stated, trips cannot be reset until 1.0s after the trip has been accepted by the drive.
No. String No. String No. String
1
UV 91 UP Par 189 EnC1
2
t002 92 UP ro 190 EnC2
3
AOC 93 UP So 191 EnC3
4
t004 94 UP ovr 192-196 t192 - t196
5
PS 95 UP OFL 197 EnC9
6
Et 96 UP uSEr 198 EnC10
7
O.SPd 97 UP udf 199 dESt
8
PS.10V 98 UP ACC 200 SL1.HF
9
PS.24V 99 t099 201 SL1.tO
10
t010 100 202 SL1.Er
11
tunE1 101 t101 203 SL1.nF
12
tunE2 102-111 t102 - t111 204 SL1.dF
13
tunE3 112-156 t112 - t156 205 SL2.HF
14
tunE4 157 F.O V L 206 SL2.tO
15
tunE5 158 AOP 207 SL2.Er
16
tunE6 159 FbL 208 SL2.nF
17
tunE7 160 Fbr 209 SL2.dF
18
tunE 161-167 t161 - t167 210 SL3.HF
19
t019 168 FdL 211 SL3.tO
20
It.AC 169 FOC 212 SL3.Er
21
O.ht1 170 SL 213 SL3.nF
22
O.ht2 171 S.OLd 214 SL3.dF
23
t023 172 S.OV 215 SL.rtd
24
th 173 th.Err 216 t216
25
thS 174 PLL Err 217-229 HF17 – HF29
26
O.Ld1 175 C.Prod
27
O.ht3 176 t176
28
cL2 177 C.Boot
29
cL3 178 C.BUSy
30
SCL 179 C.Chg
31
EEF 180 C.Optn
32-33
t032 - t033 181 C.RdO
34
Pad 182 C.Err
35
CL.bit 183 C.dat
36
SAVE.Er 184 C.FULL
37
PSAVE.Er 185 C.Acc
38-39
t038 - t039 186 C.rtg
40-89
t040 - t089 187 C.Typ
90
UP div0 188 C.cpr
Priority Category Trips Comments
1 Hardware faults HF01 to HF16
These indicate fatal problems and cannot be reset. The drive is
inactive after one of these trips and the display shows HFxx.
2 Non-resetable trips
HF17 to HF29, SL1.HF, SL2.HF,
SL3.HF
Cannot be reset
3 EEF trip EEF
Cannot be reset unless a code to load defaults is first entered in
parameter x.00
4 SMARTCARD trips
C.Boot, C.Busy, C.Chg, C.Optn,
C.RdO, C.Err, C.dat, C.FULL,
C.Acc, C.rtg, C.Typ, C.cpr,
SMARTCARD trips have priority 5 during power up.
4 Encoder power supply trips Enc1, Enc2
These trips can only override the following priority 5 trips: Enc2, Enc9
or Enc10
5 Normal trips
All other trips not included in this
table
Can be reset after 1.0s
6 Self reseting trips UV
Under voltage trip cannot be reset by the user, but is automatically
reset by the drive when the supply voltage is with specification.
