Mentor MP User Guide 161
Issue: 3 www.controltechniques.com
Table 12-31 Siba semiconductor fusing for 480V and 575V size 1 drives
Table 12-32 Siba branch circuit protection fusing for 480V and 575V size 1 drives
Table 12-33 Siba DC protection fusing for 480V and 575V size 1 drives
DC protection fusing is only required for 4 quadrant drives.
Model Fuse type
Rating
V
Rating
A
Description
Part number
(with indicator)
Part number
(without
indicator)
Auxiliary 10 x 38mm ferrule 660Vac 12 10 x 38 cylindrical 660Vac URZ 50 179 06.12
MP25A4 MP25A5
22 x 58mm ferrule
690Vac
32
22 x 58 cylindrical 690Vac URZ
50 140 06.32
MP45A4 MP45A5 63 50 140 06.63
MP75A4 MP75A5 100 50 140 06.100
MP25A4(R) MP25A5(R) 32 50 140 06.32
MP45A4(R) MP45A5(R) 63 50 140 06.63
MP75A4(R) MP75A5(R) 100 50 140 06.100
MP105A4 MP105A5
Size 000 square
body
160 URB 000 690Vac 160A bolt-type 20 282 20.160 20 282 21.160
MP155A4 MP155A5 200 URB 000 690Vac 200A bolt-type 20 282 20.200 20 282 21.200
MP210A4 MP210A5 315 URB 000 690Vac 315A bolt-type 20 282 20.315 20 282 21.315
MP105A4(R) MP105A5(R) 160 URB 000 690Vac 160A bolt-type 20 282 20.160 20 282 21.160
MP155A4(R) MP155A5(R) 200 URB 000 690Vac 200A bolt-type 20 282 20.200 20 282 21.200
MP210A4(R) MP210A5(R) 315 URB 000 690Vac 315A bolt-type 20 282 20.315 20 282 21.315
Model Fuse type
Rating
V
Rating
A
Description Part number
Auxiliary
NH 000 knife blade
690Vac
10 NH 000 gG 690Vac 10A 20 477 13.10
MP25A4 MP25A5 35 NH 000 gG 690Vac 35A 20 477 13.35
MP45A4 MP45A5
NH 00 knife blade
63 NH 00 gG 690Vac 63A 20 209 13.63
MP75A4 MP75A5 100 NH 00 gG 690Vac 100A 20 209 13.100
MP25A4(R) MP25A5(R) NH 000 knife blade 35 NH 000 gG 690Vac 35A 20 477 13.35
MP45A4(R) MP45A5(R)
NH 00 knife blade
63 NH 00 gG 690Vac 63A 20 209 13.63
MP75A4(R) MP75A5(R) 100 NH 00 gG 690Vac 100A 20 209 13.100
MP105A4 MP105A5
NH 1 knife blade
160 NH1 gG 690Vac 160A 20 211 13.160
MP155A4 MP155A5 200 NH1 gG 690Vac 200A 20 211 13.200
MP210A4 MP210A5 NH 2 knife blade 315 NH2 gG 690Vac 315A 20 212 13.315
MP105A4(R) MP105A5(R)
NH 1 knife blade
160 NH1 gG 690Vac 160A 20 211 13.160
MP155A4(R) MP155A5(R) 200 NH1 gG 690Vac 200A 20 211 13.200
MP210A4(R) MP210A5(R) NH 2 knife blade 315 NH2 gG 690Vac 315A 20 212 13.315
Model Fuse type
Rating
V
Rating
A
Description Ref number Configuration
MP25A4R MP25A5R
20 x 127mm cylindrical 1000Vdc
32 20 x 127 1000Vdc 32A gR 90 080 10.32 single fuse
MP45A4R MP45A5R 50 20 x 127 1000Vdc 50A gR 90 080 10.50 single fuse
MP75A4R MP75A5R 36 x 190mm cylindrical 1500Vdc 80 36 x 190 1500Vdc 80A gR 90 094 10.80 single fuse
MP105A4R MP105A5R
SQB-DC2 square body 900Vdc
125 SQB-DC2 1200V 125A 90 203 25.125 single fuse
MP155A4R MP155A5R 160 SQB-DC2 1200V 160A 90 203 25.160 single fuse
MP210A4R MP210A5R 250 SQB-DC2 1200V 250A 90 203 25.250 single fuse
NOTE
