42 Mentor MP User Guide
www.controltechniques.com Issue: 3
Table 4-13 Ferraz Shawmut semiconductor fusing for size 2 drives
A50QS series are only rated up to 500Vac.
*Application overload limited to infrequent overloads to avoid fuse wear out
**Fuse limits applications to those operating at rated current. No cyclic overloads permitted.
Model
International USA
Description Catalogue number Ref number Description Catalogue number Ref number
Field fuses
10 x 38mm
Ferrule
FR10GB69V25 L330014 10 x 38mm Ferrule FR10GB69V25 L330014
MP350A4
Square Body
Fuses
PC30UD69V500TF W300399
American Round
Fuses Form 101
Range A70QS
A50QS450-4
A7OQS450-4
EQ16871
F214848
MP350A4R PC71UD11V500TF F300523 A7OQS450-4 F214848
MP350A5
MP350A6
PC31UD69V500TF T300006
A70QS450 F214848
MP350A5R
MP350A6R
PC72UD13C500TF D300498
MP420A4 PC32UD69V630TF M300069
A50QS600-4
A70QS600-4
Q219457
Y219993
MP420A4R PC272UD13C630TF W300721 A70QS600-4 Y219993
MP470A5
MP470A6
PC272UD13C700TF X300722
2 x A70QS400
in parallel
J214345 (x2)
MP470A5R
MP470A6R
MP550A4 PC33UD69V700TF Y300079
A50QS700-4
A70QS700-4
N223181
E202772
MP550A4R PC272UD13C700TF X300722 A70QS700-4 E202772
MP700A4 PC32UD69V1000TF S300074
A50QS900-4
2 x A70QS500-4
in parallel
R212282
A218431 (x2)
MP700A4R PC72UD10C900TF G300869
2 x A70QS500
in parallel.
A218431 (x2)
MP700A5
MP700A6
PC32UD69V1000TF S300074
MP700A5R
MP700A6R
PC73UD12C900TF T300512
MP825A4 PC32UD69V1100TF M300759
A50QS1200-4
2 x A70QS600-4
in parallel
C217904
Y219993 (x2)
MP825A5
MP825A6
PC33UD69V1100TF C300083
2 x A7OQS600-4
in parallel
Y219993 (x2)
MP825A4R
MP825A5R
MP825A6R
PC73UD95V800TFB W300514
MP900A4 PC33UD69V1250TF D300084
A5 0Q S1 20 0- 4
2 x A7OQS600-4
in parallel
C217904
Y219993 (x2)
MP900A4R PC73UD95V800TFB W300514
2 x A7OQS600-4
in parallel
Y219993 (x2)
MP1200A4 PC33UD60V1600TF Z300586
2 x A5OQS800-4
in parallel.
2 x A70QS800-4
in parallel
C202287 (x2)
Z213830 (x2)
MP1200A4R PC273UD11C16CTF J302228
2 x A70QS800-4
in parallel
Z213830 (x2)
MP1200A5
MP1200A6
PC232UD69V16CTD W300215
MP1200A5R
MP1200A6R
PC273UD11C16CTF J302228
MP1850A4
**7,5 URD 44 PPSAF
2200
**K235184
2 x A5OQS1000-4
in parallel.
*3 x A7OQS700-4
in parallel
B217391 (x2)
*E202772 (x3)
MP1850A4R
*3 x A7OQS700-4
in parallel
*E202772 (x3)
MP1850A5
MP1850A6
MP1850A5R
MP1850A6R
NOTE
