Emerson Process Management GmbH & Co. OHG1-2
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
1.1 Overview
All X-STREAM XE gas analyzers feature
an easy-to-use LCD graphic user interface,
which displays measurement values, status
and error messages, and menus for the input
of parameters.
Measurement and status information are vi-
sualized with plain text and symbols.
The symbols are designed to indicate the dif-
ferent status “Failure”, “Function check”, “Out
of specication” and “Maintenance request” as
specied by the NE 107 standard. For further
information, X-STREAM Enhanced Se-
ries instruction manual.
The analyzer software is operated by means
of only six keys.
For ease of use, the operator can select one of
three languages for the display: By default any
analyzer is congured with English and Ger-
man language sets, while a third can option-
ally be added. Currently available: French,
Italian, Portuguese and Spanish.
1.1.1 Housings
The displays of outdoor versions are protected
with an impact tested glass panel, to withstand
even harsher conditions and to provide a higher
IP protection class of up to IP66 / NEMA Type
4X.
1.1 Overview
1.1.2 The Front Panel
Different housings allow X-STREAM analyz-
ers to be tailored to many different applica-
tions:
• Tabletop units in
1
⁄219in modular design,
with IP 20 protection class. Can be in-
stalled into a rack or used as a table top
instrument. Optionally featuring a handle
enabling mobile measurements at differ-
ent sampling points.
• Tabletop and rack mountable units in 19in
modular design, with IP 20 protection
class.
• Stainless steel wall mountable eld hous-
ing XEXF with IP 66 / NEMA 4X protection
class enables outdoor use (operating tem-
perature -20°C to +50°C [-4 °F to 122 °F]).
• Cast aluminium wall mountable eld hous-
ing with IP 66 / NEMA 4X protection class
for outdoor use (operating temperature
-20 °C to +50 °C [-4 °F to 122 °F]). Spe-
cially designed to meet hazardous area
certications, but also suitable for non-
hazardous locations with requirements for
robust designed equipment.
