Emerson Rosemount Analytical X-STREAM Enhanced Series User Manual

Emerson Process Management GmbH & Co. OHG 3-5
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
3
Startup
3.4.3 Keys
Six keys enable the use of the menu system.
Depending on the operational mode (measur-
ing, browsing menus, editing) they have the
following functions:
enter key:
Mode Function
Measuring Enter main menu
Browsing
Open submenu (..) or
execute command (!)
Editing Conrm new entry
home key:
Mode Function
Measuring (no function)
Browsing Return to measurement display
Editing Abort entry
up / down keys:
Mode Function
Measuring Enter main menu
Browsing
Highlight next menu line
Open the previous/next page,
when currently a line beginning
with / is highlighted
Editing Change current parameter
3.4 Front Panel Elements
