Emerson Rosemount Analytical X-STREAM Enhanced Series User Manual

Emerson Process Management GmbH & Co. OHG3-28
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
3.9 Web Browser
IP address for Ethernet2 connector
To directly gain access to the instrument´s
web browser interface, rst ensure the in-
strument is powered. Next connect it to the
computer's network adapter via Ethernet2
connector (see Fig. 3-4) by means of an Eth-
ernet cross-over cable. Standard Ethernet
cables do NOT support direct connections!
• For Ethernet2 connector "Use DHCP" is
always set to No (see gure to the left).
• Depending on settings possibly carried out
earlier, the analyzer may now show an IP
(see gure to the left). If so, setup your com-
puter's IP the same way, only differing in
the last group (here e.g. to 123.456.78.10).
Note:
Ethernet2's IP address has to be in another
subnet than Ethernet1's IP address.
Alternatively you may use the analyzer's xed
IP, that is not shown on any menu page and
is accessible via Ethernet2 only:
• The analyzer is now assigned the IP
192.168.1.88.
• Congure your computer to use a new IP
of the same net (e. g. 192.168.1.10).
3.9.2 Connection to Single Computer
Conguring an IP Address for Computers Running Microsoft Windows
• To congure your computer you need an administrator account!
• Go to Start > Control Panel > Network Connections
• Right-click on your LAN connection and click "Properties"
• Under the heading "This connection uses the following items", click "Internet Protocol (TCP/IP)"
• Click "Properties"
• A new window should pop up, click "Alternate Conguration"
• Click "User Congured" radio button
• Setup the IP Address as 192.168.1.10, Subnet Mask as 255.255.255.0 and Default Gateway as 192.168.1.1.
• Click "OK"
• Click "Close" in "LAN connection properties".
On your computer open a web browser and
enter the instrument´s IP address. If every-
thing is congured properly, the analyzer's
logon screen shows up ( next page ).
Ethernet2
MAC 123456789
IP: 123.456.78.9
Subnet: 255.255.255.0
Gateway: 123.456.78.0
Use DHCP: No
IP Status Ready
Apply Conguration!

Setup..
Communcation..
Ethernet2..
