Emerson Process Management GmbH & Co. OHG 2-17
X-STREAM XE
Short Form Manual
HASXEE-SFM-HS
05/2017
2
Installation
All dimensions in mm
[inches in brackets]
Cable glands
Connector
for potential
equalization
Gas ttings
Fig. 2-10: X-STREAM XDF - Dimensions for Installation
Note!
Take care to reserve space
at the right side of the instru-
ment for laying the cables!
