e
Select Brightness, and then use the [ ][ ] buttons to adjust the
brightness.
f
Return to step 2 and adjust each level.
g
Press the [Esc] button to return to the previous screen.
Displaying a Scaled Image
A section of the image is cropped and displayed. This allows you to create
one large image by combining images projected from multiple projectors.
a
Project the image, and then press the [Menu] button.
b
Select Multi-Projection from Extended.
a
You can also perform the same operation from Scale in
Signal.
c
Select Scale, and then press the [ ] button.
d
Turn on Scale.
(1)
Select Scale, and then press the [
] button.
(2)
Select Auto or Manual, and then press the [
] button.
Auto: Automatically adjusts the clipped area according to the adjustment
values in Edge Blending and Tiling. You do not need to perform any steps
after step 6.
Manual: Allows you to adjust the clipped area manually.
(3) Press the [Esc] button to return to the previous screen.
a
If auto adjustment does not work for the clipped image, adjust
the aspect ratio, and then select Auto.
s "Changing the Aspect Ratio of the Projected Image "
p.78
e
Set Scale Mode.
(1)
Select Scale Mode, and then press the [
] button.
Multi-Projection Function
102
To Next Page
