Preparing
21
Preparing the Remote Control
Installing the Remote Control Batteries
Attention
•
Check the positions of the (+) and (-) marks inside the battery holder to ensure the batteries are inserted the
correct way.
•
You cannot use other batteries except for AAA size manganese or alkaline.
a
Remove the battery cover.
While pushing the battery compartment
cover catch, lift the cover up.
b
Replace the old batteries with new
batteries.
Check the polarity of the batteries (+) and
(-) before installing.
c
Reattach the battery cover.
Press the cover until it clicks into place.
c
If delays in the responsiveness of
the remote control occur or if it
does not operate, it probably
means that the batteries are
becoming flat. Replace with two
new batteries (AAA size
manganese or alkaline batteries).
Remote Control Operating Range
Operating range (left to right)
30°
30°
6m
55°
55°
55°
55°
6m
Operating range (top to bottom)
6m
6m
15°
60°
60°
To Next Page
