B
Battery cover Open when installing or removing the optional battery.
C
Maintenance box cover Open when replacing the maintenance box.
D
DC inlet Connects the AC adapter.
Removing the Handle
This printer can be used without the handle. To remove the handle, move the handle forward, grasp it with both hands,
and then spread it outwards.
After removing the handle, be sure to attach the handle hole caps th at came wit h your printer; o th erw is e dust or f oreign
substances may enter the printer.
c
Important:
Keep the handle hole caps out of the reach of children.
Note:
When you reattach the handle, check the shapes of the handle and handle holes. You cannot attach the handle in the wrong
direction.
PM-520 Operation Guide
Printer Basics
12
