EVCO S.p.A. c-pro 3 nano CHIL | Application manual ver. 1.0 | Code 144CP3NCHE104
page 19 of 90
6.6 User Menu
The user menu is a Level 1 menu; this means that you must type the User level (or higher) password to be able to view/change the
parameters in this branch.
6.7 Maintenance Menu
The maintenance menu is a Level 2 menu; this means that you must type the Maintenance operator level (or higher) password to be
able to view/change the parameters in this branch.
Vgraph Display LED display
OPERATION OPEr
MANUAL MAnU
CALIBRATION CAL
IN/OUT I-O
PASSWORD PSd2
In this menu you can view the mode of the different devices, inputs, and outputs used by the application.
In this OPERATING menu you can view/enable the functions for the operation of compressors, fans, and pumps. Some examples are
represented by the operating hours, by the threshold of maximum hours permitted.
In the MANUAL menu you can set the manual/automatic operation of compressors, pumps, and fans, whose outputs may be forced to
test their operation.
In the CALIBRATION menu you can set the corrections to be applied to the analogue outputs to compensate the offsets due to the
cabling and the positioning of the probe.
In the I/O MODE menu you can directly view the physical inputs and outputs of the board.
6.8 Installer Menu
The installation menu is a Level 3 menu; this means that you must type the installation level (or higher) password to be able to
view/change the parameters in this branch.
Vgraph Display LED display
COMPRESSORS CoMP
REGULATION rEG
FANS FANS
DEFROST dEFr
PUMPS PuMP
ANTI-FREEZE A-F
FREE-COOLING F-C
SAFETY DEVICES SAFE
MODBUS MdbS
MISCELLANEOUS Par
SAVE/RESTORE MAp
PASSWORD PSd3
The installation operator menu contains all the parameters on configuration of all the functions (alarms, settings, logic, type of rotation,
etc.) of the machine.
In the REGULATION menu you can set the parameters for temperature control of the compressors in the lateral band and in the zero
energy band.
In the COMPRESSOR menu you can set the parameters for management of the devices:
• rotation
• timing
• Maximum number of start-ups.
