page 41 of 90
15-16 Pump 1 thermal switch heat source exchanger NC-NO
17-18 Pump 2 thermal switch heat source exchanger NC-NO
19-20 Free-cooling external fan thermal switch NC-NO
21-22 High-pressure Circuit 1 NC-NO
23-24 Low-pressure Circuit 1 NC-NO
25-26 Compressor1 thermal switch NC-NO
27-28 Compressor2 thermal switch NC-NO
29-30 Compressor3 thermal switch NC-NO
31-32 Fan thermal switch Circuit 1 NC-NO
33-34 High-pressure Circuit 2 NC-NO
35-36 Low-pressure Circuit 2 NC-NO
37-38 Compressor thermal switch 4 NC-NO
39-40 Compressor thermal switch 5 NC-NO
41-42 Compressor thermal switch 6 NC-NO
43-44 Fan thermal switch Circuit 2 NC-NO
7.4 AO Configuration
Below is the table of values for configuration of the positions of the analogue outputs of the controller and the expansion.
Parameters
Analogue Output
HC01 HC02
HC05 HC06
HC03 HC04
HC07 HC08
HC09 HC10
0 0 0 Disabled
1 1 1 Free-cooling three-way valve (0-10V)
2 2 2 Free-cooling external fan (0-10V)
3 3 3 Ventilation Circuit 1 (0-10V)
4 4 4 Water valve Circuit 1 (0-10V)
5 5 5 Ventilation Circuit 2 (0-10V)
6 6 6 Water valve Circuit 2 (0-10V)
7 - - Free-cooling external fan (PWM)
8 - - Ventilation Circuit 1 (PWM)
9 - - Ventilation Circuit 2 (PWM)
- 7 - Free-cooling external fan (4-20mA)
- 8 - Ventilation Circuit 1 (4-20mA)
- 9 - Ventilation Circuit 2 (4-20mA)
7.5 DO Configuration (HD01-HD18 parameters)
Below is the table of values for configuration of the positions of the digital outputs of the controller and the expansion.
Parameters
HD01-HD18
Digital Output
0 Disabled
1-2 Pump 1 plant NC-NO
3-4 Pump 2 plant NC-NO
5-6 Pump 1 source NC-NO
7-8 Pump 2 source NC-NO
9-10 Free-cooling external fan NC-NO (On/Off or Enable)
