EVCO S.p.A. c-pro 3 nano CHIL | Application manual ver. 1.0 | Code 144CP3NCHE104
page 45 of 90
Digital inputs EVDRIVE03 circuit 1
D/I 1 VCM1 High pressure C1 High pressure C1
D/I 2 VCM1 Low pressure C1 Low pressure C1
D/I 3 VCM1 Compressor 1 thermal switch Compressor1 thermal switch
Digital inputs EVDRIVE03 circuit 2
D/I 1 VCM2 None High pressure C2
D/I 2 VCM2 None Low pressure C2
D/I 3 VCM2 None Compressor 4 thermal switch
Analogue Outputs Controller
A/O 1 VentilationC1 (PWM) Ventilation C1 (PWM)
A/O 2 Not used Ventilation C2 (PWM)
A/O 3 Not used Not used
A/O 4 Not used Not used
Digital Outputs Controller
D/O 1 Pump 1 plant (NO) Pump 1 plant (NO)
D/O 2 Compressor 1 (NO) Compressor 1 (NO)
D/O 3 Compressor 2 (NO) Compressor 4 (NO)
D/O 4 Anti-freeze heater plant C1 (NO) Anti-freeze heater plant C1 (NO)
D/O 5 Ventilation C1 (Enable) (NO) Ventilation C1 (Enable) (NO)
D/O 6 Compressor 3 (NO) Ventilation C2 (Enable) (NO)
D/O 7 Not used Not used
Digital Outputs EVDRIVE03 circuit 1
D/O VCM 1 Solenoid valve C1 Solenoid valve C1
Digital Outputs EVDRIVE03 circuit 2
D/O VCM 2 None Solenoid valve C2
8.2.2 Water/water and air/water chillers (NO EVDRIVE03)
PGUT=2 and 6 (1 Circuit) PGUT=10 and 14 (2 Circuits)
Analogue inputs Controller
A/I 1 Heat sink exchanger input temperature Heat sink exchanger input temperature
A/I 2
Heat sink exchanger output temperature
Circuit 1
Heat sink exchanger output temperature
Circuit 1
A/I 3 Not used Not used
A/I 4 Compressor discharge temperature C1 Compressor discharge temperature C1
A/I 5 Not used Not used
A/I 6 Compressor thermal switch 1 (NC) Compressor thermal switch 1 (NC)
A/I 7 Thermal switch pump 1 plant (NC) Compressor discharge temperature C2
A/I 8 Not used Condensation pressure C2 (4-20mA)
A/I 9 Pressure pressure C1 (4-20mA) Condensation pressure C1 (4-20mA)
Digital Inputs Controller
D/I 1 On/Off Compressor thermal switch 2 (NC)
D/I 2 Heat sink exchanger flow switch (NC) Heat sink exchanger flow switch (NC)
D/I 3 Fan thermal switch C1 (NC) Fan thermal switch C1 (NC)
D/I 4 Low pressure C1 (NC) Low pressure C11 (NC)
D/I 5 High pressure C1 (NC) High pressure C1 (NC)
