In the FANS menu you can set the parameters relative to condensation pressure control with the fans.
In the DEFROST menu you can set the parameters for activation and duration of heat pump defrost.
In the PUMP menu you can set the parameters for operation and protection of the pumps.
In the ANTI-FREEZE menu you can set the parameters for thermal control of the resistors and control of the anti-freeze alarm.
In the FREE-COOLING menu you can set the parameters for the free-cooling function and its damper.
The SAFETY DEVICE menu contains all the parameters relative to the alarms and management of the safety devices, which protect the
refrigerator circuit:
• activations
• delay reports
• type of reset.
In the MODBUS menu you can set the parameters for the Modbus.
The MISCELLANEOUS PARAMETERS menu contains other general parameters for management of the Modbus communications, end of
scale values of the transducer, and other configurable activations.
From the SAVE/RESTORE menu you can restore the preset values of all the application’s parameters and save them or download them
from the programming key or from the controller’s internal memory.
6.9 Manufacturer Menu
The configuration menu is a Level 4 menu; this means that you must type the configuration level password to be able to view/change
the parameters in this branching. Furthermore, this level may only be accessed with the machine in OFF mode.
Vgraph Display LED display
CONFIGURATION ConF
HARDWARE
H-AI
H-dI
H-AO
H-dO
EVCM C1-C2
vCM1
vCM2
PASSWORD PSd
This menu lists all the machine’s configuration parameters, which determine its operating mode and whose functions must be enabled
or disabled.
The CONFIGURATION menu contains the parameters for machine configuration.
The HARDWARE menu lets you configure the unit’s I/O.
The ECM menu lets you configure the main parameters of the EVDRIVE03 for each circuit.
6.10 RTC Menu
This menu covers the functions of the Real-Time Clock System, like setting the real-time clock and the daily scheduler (parameters
PTxx).
6.11 Alarm Menu
This menu lets you view and turn off the alarms.
