FAAC SDK EVO User Manual

E1SL 36 532258 04 - Rev. B
Translation of the original instructions
ENGLISH
11 Errors and Warnings
Errors (AUTORESET): after the error has been active for 30 s the board attempts to RESET (maximum 5 attempts).
Errors and Warnings
(codes on grey background = warnings)
Required action (perform
RESET after the intervention)
1
BOARD FAILURE (AUTORESET) Perform RESET. If the problem persists, replace the control board.
4
VACC FAULT Accessories power supply fault (VACC)
Make sure that there is not a short circuit between pins V and G on the terminal board. Make sure that
the current drawn by the accessories connected to the board is within the permitted limits. Check fuse
F2 Perform
RESET. If the problem persists, replace the control board.
5
UC FAULT Microcontroller error (AUTORESET)
Make sure that there are NO sources of electromagnetic interference that are too close to the board. Update
the board with the latest FW version available.
7
MOTOR FAILURE (AUTORESET)
Make sure that the automation type has been selected correctly. Make sure that the motor has been con-
nected properly. If the problem persists, replace the motor.
9
VMAIN FAULT
With the Emergency battery connected, make sure that the battery has been enabled via the board or the
SDK EVO.
Check the mains voltage and the switching power supply unit.
10
BATTERY DISCHARGED (Deep Sleep)
With the emergency battery connected, if the battery charge level is low, it does not allow any move-
ment. Turn the mains power back on.
11
12
TEST on S1 configured as SAFETY failed (AUTORESET)
TEST on S2 configured as SAFETY failed (AUTORESET)
Check the connection and operation of the safety device.
Check the programming of input S1- S2.
15
SETUP INHIBITED
Make sure that the automation type has been selected correctly, or that Night or Manual operating mode has
not been selected, or that an emergency input is not active, or that the automation is NOT operating with the
battery due to a mains power failure.
16
ENCODER FAILURE (AUTORESET) Make sure that the encoder is connected properly. If the fault persists, replace the motor or the board.
18
FIRMWARE NOT COMPATIBLE
During the update, an incompatible FW has been detected. Check and update the automation board FW via
the USB storage device.
19
HIGH MECHANICAL FRICTION (AUTORESET)
Check the leaves slide smoothly with power supply, battery and motors disconnected. Remove any fric-
tion. Check the counter wheel.
20
TEST on Inputs configured as SAFETY failed (AUTORESET) Check the connections and the programming of the inputs and the safety devices.
22
BOARD CONFIGURATION DATA NOT VALID Program the Model of the automation from the board (CF) or the SDK EVO.
23
POWER UNIT FAILURE Switching power supply unit failure. Replace the power supply.
24
NUMBER OF CONSECUTIVE OBSTACLES DURING CLOSING
Check for and remove the obstacle. Check the leaves slide smoothly with power supply, battery and motors
disconnected.
26
LOCK FAILURE (AUTORESET)
Make sure that the motor block has been installed, connected and configured correctly. If warning
59
appears, make sure that the SURVEILLANCE KIT has been installed and connected correctly. If warning
54
appears, replace the board or the motor block.
27
MOTOR ROTATION FAULT Check belt connection to the leaves.
29
DM BOARD FAULT (AUTORESET) Check the DM errors table via the SDK EVO.
31
NUMBER OF CONSECUTIVE OBSTACLES DURING OPENING
Check for and remove the obstacle. Check the leaves slide smoothly with power supply, battery and motors
disconnected.
32
MOTION TIMEOUT
Motor without limit switch reference positions; check that it is installed correctly and the mechanical
stops. Check the motor wiring. If the problem persists, replace the board or motor.
38
CONFIGURATION ERROR Programming has been carried out that requires a new SETUP. Perform SETUP. Check the programming.
39
SETUP DATA NOT VALID/MISSING Perform SETUP. If the problem persists, replace the board or motor.
41
DATE / TIME MISSING Reset the time and date via the SDK EVO.
42
DATE / TIME BATTERY DISCHARGED or MISSING Replace the clock battery
43
SYSTEM TEST IN PROGRESS The system TEST is running.
44
EMERGENCY ACTIVE Emergency input is active.
45
TIMER ACTIVE The TIMER is enabled.
46
TIMER ACTIVE IN PROGRESS A TIMER function is running.
47
LAST MOVEMENT CARRIED OUT WITH BATTERY The automation has carried out the last programmed movement using the battery.
48
NIGHT-TIME MODE IN PROGRESS Night-time mode operation.
49
MANUAL MODE IN PROGRESS Manual mode operation.
50
PARTIAL MODE IN PROGRESS Partial mode operation.
51
OBSTACLE DETECTED WHEN CLOSING Check for and remove the obstacle.
52
OBSTACLE DETECTED WHEN OPENING Check for and remove the obstacle.
