Integrated Network Analyzer
Using the Analyzer
29
Network
monitoring
Cable test
live network
NIC testing
Cable test
terminated cable
MDI
MDI-X
Cable test
open cable
aww06f.eps
Figure 16. Cable Test Capabilities
Note
If you have purchased the optional OptiView Fiber Inspector
product, it can be launched from the Cable Test screen by pressing
the
button.
Setting Up a Printer
You can add printers through the desktop (Start | Printers and Faxes | Add a
Printer).
Note
By default, a PDF print driver, called “OptiView PDF Printer”, has
been installed and configured to print to file. By default, the PDF file
is saved in the My Documents folder. When printing to a PDF file,
do not check the Print to file check box in the Printer dialog.
