Table 2. Error Codes
Table 3. Fault Warning Codes
RPM
Display
Message
Display
Probable Cause
Note: Not all inputs are used for all engines.
E01 NO DATA
>J1939 CAN bus cable not connected / connected to wrong port
>Broken wire / bad connector contact on cable
E02 NO RPM
Engine RPM not detected
>Data cable not connected / connected to wrong port
>Engine not running / ignition key on
>Broken wire / bad connector contact on alternator cable
E04 NO OIL
SENSOR
No Engine Oil Pressure Data Detected (w/separate sensor input)
>Sensor cable not connected
>Broken wire / bad connector contact on sensor cable
>Defective pressure sensor
E05 NO D. PSR
SENSOR
No Discharge Pressure Sensor Detected
>Sensor cable not connected
>Broken wire / bad connector contact on sensor cable
>Defective pressure sensor
E06 NO I. PSR
SENSOR
No Intake Pressure Sensor Detected
>Sensor cable not connected
>Broken wire / bad connector contact on sensor cable
>Defective pressure sensor
E07 NO ENG T
SENSOR
No Coolant Temperature Data Detected (w/separate sensor input)
>Sensor cable not connected
>Broken wire / bad connector contact on sensor cable
>Defective temperature sensor
E16 NO FRC
DATALINK
>FRC datalink cable not connected / connected to wrong port
>Broken wire / bad connector contact on cable
Error Codes and Fault Warnings
RPM
Display
Message Display Description Factory
Default Setting
F01 HI BATT VOLTAGE
High Battery Voltage 15.5 V
F02 LOW BATT VOLTAGE
Low Battery Voltage 11.8 V*
F03 HI TRANS TEMP
High Transmission Temperature 300 °F
F04 LOW OIL PRESSURE
Low Engine Oil Pressure 8 PSI**
F05 DPFR
Discharge Sensor High Voltage
F06 IPFR
Intake Sensor High Voltage
F07 HI ENG TEMP
High Engine Coolant Temperature 220 °F**
F08 NO WATER
Out of Water Mode
F09 ENG NOT RESPOND
Engine Does Not Respond
* 11.8 engine running, 11.7 engine off.
Note: E5 and E6 show on a remote governor not programmed correctly (code P303).
** J1939 compliant—engine ECM will issue this warning.
To Next Page
