FRC InControl TGA400 User Manual

TGA300 Rev180405
25
Table 5. Calibration Codes Quick Reference Chart
CALIBRATION
Three programs are available after the calibration password code has been entered:
C1 - Discharge Pressure Sensor Zero Calibration
C2 - Intake Pressure Sensor Zero Calibration
C3 - Engine RPM Calibration
Refer to Table 5. Calibration Codes Quick Reference Chart.
Enter Calibration Password Code 1111
Note: To exit the programming mode, press the SILENCE button when the
program code ashes in the RPM display.
1. Enter the password code 1111. (Refer to Programming Section.)
Result: When the correct password code is entered C 1 ashes in the
RPM display. The message display shows D.PSI.
2. Press the PRESSURE or RPM buttons when the program (C) code is
ashing to scroll through the program codes.
Refer to specic calibration section for detailed procedures.
Note: If there is a failure during calibration the message display shows
SENSOR PROBLEM.
3. Press the SILENCE button when the program (C) code is ashing to exit.
CODE DESCRIPTION MESSAGE
DISPLAY
Press MENU
Button Again
Press MENU
Button Again
C1 Discharge Pressure
Sensor Zero Calibration
D.PSI D.PSI
SET P=0?
D.PSI
D.PSI=0
C2
Intake Pressure Sensor
Zero Calibration
I.PSI I.PSI
SET P=0?
I.PSI
I.PSI=0
C3 Engine RPM Calibration CAL.
ENG RPM
SET RPM
XXXX
