TGA300 Rev180405
19
Detailed Information
The four LED bar graphs provide constant display of safe operating ranges for
engine oil pressure, engine coolant temperature, transmission temperature, and battery
voltage. They do not show exact numbers or units of measure. Detailed information is
shown in the message display when the MENU button is pressed. Engine hours, and
pump hours are also shown.
Show Detailed Information
Note: Detailed information is a display only mode and no changes can be
made to the data.
The MENU button allows the operator to gain access to detailed information. Each
time the MENU button is pressed the display scrolls to show the next value.
The message display indicates the following:
ENG TEMP ### °F (programmable for °C)
ENG OIL ### PSI (programmable for kPa or Bar)
BATT VDC ##.# V (programmable for 12V or 24V)
ENG HRS ####
PUMP HRS ####
TRANS T. ### °F (programmable for °C)
D.SENSOR #### PSI (programmable for kPa or Bar)
I.SENSOR #### PSI (programmable for kPa or Bar)
The message display reverts to normal operation after 20 seconds if no buttons are
pressed. When a button other than the MENU button is pressed, the display immediately
reverts to normal operation. The SILENCE button should be used during operations.
High-Idle
The governor programming includes a high-idle function. To activate the high-idle
set all interlocks as called for by local SOP (normally this would include the transmission
in neutral and the parking brake on). Set the High-Idle switch to ON.
Note: The pump must NOT be engaged when using the high-idle function
and the THROTTLE READY LED will be off.
Change High-Idle Setting
Note: The high-idle is set at about 1000 RPM at the factory. (This value
varies depending on the specic engine.)
1. With the engine running, set the high-idle switch to ON.
Result: Engine goes to high idle RPM.
