Working with the note book
Removing the card
Always remove the card according to the rules described below, to
ensure that none of your data is lost.
You can stop the card using the co rresponding icon in the task bar:
► Left click on the icon to safely remove hardware, located in the taskbar.
► Select th e c ard y ou want to stop
and remove.
► Press the "Enter" key.
Wait fo r the dialog b ox which tel
ls you that it is now safe to remove the card.
1
2
► If the eject button is lowered, you must
first cause the eject button to release
from the notebook casing. To do this,
press the eject button until it pops out.
Press the eject button (1) so that the card
protrudes a little fro m the notebook.
► Pull the card out of the slot (
2).
► Insert the card placeholder into the
slot guide.
► Carefully s lide the placeholder for the
cardasfarasitwillgointotheslot.
Do not use excessive force.
Loudspeakers and microphones
Microph
one
Loudspe
akers
Basslou
dspeaker (subwoofer)
Volum ec
ontrol
Information on the exact position of the speakers and microphone can be
found in "
Ports and con trols", Page 9.
Please refer to chapter "
Key combinations", Page 25 for information on setting the v olume
and also enabling/disa bling the loudspeakers using key combinations.
If you attach an ext ernal microphone, the built-in microphone is disabled.
When you connect headphones or exte rnal spe akers, the built-in speakers are disabled.
Information on con nect ing headphones and a microphone can be found
in "
Connecting externa l devices", Page 50.
Fujitsu Technology Solutions 41
