Removing an d installing components
during servicing
Installing the optical drive
1
2
2
1
► Slide th e drive into the notebook (1).
► Fasten the screw s (2).
► Complete the removal, see "
Finishing component removal", Page 65.
Finishing component removal
After you have removed or changed the system c omponen ts as you required, please
prepare your device for operation again as follows:
► Install the battery again (see "
Installing a batte ry", Page 33).
► Turn the notebook the right way up again and place it on a flat surface.
► Reconnect the cables that you disconnected before.
Fujitsu Technology Solutions 65
