Working w ith the notebook
SIM card
A S IM Card (Subscriber Identity Module) is a chip card which is inserted in a mobile telephone or
notebook to enable access to a mobile radio netwo rk in conjunction with an installed UMTS module.
Follow the instructions supplied by the provider of the SIM card.
The SIM card slot is located in the battery compartment and can only
be accessed when the battery is removed.
Inserting the SIM card
► Prepare for insertion of the SIM card, see chapter "Preparing to remove components", Page 58.
► If necessary, open the clip (a) of the SIM card.
1
2
a
► Slide the SIM card into the slot (1)
until it enga ges, as shown in the
battery compartment.
► Slide the SIM card lock (a) in the
direction of the arrow (2).
► C omplete the insertion, see chapter "
Finishing compone nt removal", Page 65.
Removing a SIM card
► Prepare for removal of the SIM card, see chapter "Preparing to remove components", Page 58.
a
1
2
► Slide the SIM card lock (a) in the
direction of the arrow (1).
► Press on the edge of the SIM card so that
it jumps up slightly out of the slot.
► Pull the SIM card out of the slot in the
direction of the arrow (2).
► C omplete the removal, see chapte r "
Finishing component removal", Page 65.
42 Fujitsu Technology Solutions
