1. OPERATION
1-41
1
1.24 Setting Up Nav Data Displays
The user may arrange the nav data displays as desired.
1. Press  or  key to when nav data display is shown.
Next setting window will be displayed.
2. Use  or  to select a data display window desired.
Cursor is shown in yellow in currently selected data window.
3. Use  or  to select the item to display.
The items that can be displayed depend on the screen division.
Items displayable in (1) - (3)
XTE (course), wind speed and direction, depth, atmospheric pressure
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
Two-data
display
Three-data
display
Four-data
display
㼄㼀㻱㻦㻌㻯㼛㼡㼞㼟㼑㻌㼐㼑㼢㼕㼍㼠㼕㼛㼚
㻾㼚㼓㻦㻌㻰㼕㼟㼠㼍㼚㼏㼑㻌㼠㼛㻌㼠㼔㼑㻌㼣㼍㼥㼜㼛㼕㼚㼠㻌㼐㼑㼟㼠㼕㼚㼍㼠㼕㼛㼚
㻿㼀㻮㻰㻦㻌㻿㼠㼍㼞㼎㼛㼍㼞㼐
㻹㼍㼤㻦㻌㻹㼍㼤㼕㼙㼡㼙䚷䚷䚷䚷䚷䚷㻹㼕㼚㻦㻌㻹㼕㼚㼕㼙㼡㼙
XTE
Wind speed/direction
Depth
Atmospheric pressure
True(or Apparent)
About wind speed/direction
True: Assuming the wind speed/direction when the
ship is stopped (bow as standard)
Apparent: Apparent wind speed and direction, taking into
account the ship's movement (bow as standard)
BAROM PRESSDEPTH
WIND
Abbreviatons/meanings
at the top of the screen
