190-02692-00 Rev. A
Garmin G1000 Pilot’s Guide for the Piper PA-32 Saratoga
91
ENGINE INDICATION SYSTEM
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
1
Manifold Pressure Displays engine manifold pressure inches of mercury (IN HG).
Turbocharged Aircraft – Maximum manifold pressure range displayed in red.
2
Tachometer
Displays engine tachometer in revolutions per minute (RPM).
3
Fuel Quantity Displays left (L) and right (R) fuel quantity in gallons (GAL).
4
Fuel Flow Displays fuel flow in gallons per hour (GPH).
5
Oil Temperature Displays oil temperature in degrees Fahrenheit (°F).
6
Oil Pressure Displays oil pressure in pounds per square inch (PSI).
7
Exhaust Gas Temperature Displays Exhaust Gas Temperature in degrees Fahrenheit (°F).
8
Turbine Inlet Temperature Displays Turbine Inlet Temperature in degrees Fahrenheit (°F).
9
Cylinder Head Temperature Displays Cylinder Head Temperature in degrees Fahrenheit (°F).
10
Emergency Battery Voltage Displays the emergency battery current in voltage (V).
11
Essential Buss Voltage Displays the essential bus current in voltage (V).
12
Main Alternator Current
Standby Alternator Current
Displays main alternator current in amperes (A).
In the even the main alternator fails, the system will change to display the standby
alternator.
