Figure 2-2 Additional PFD Information
1
Selected Heading
2
Wind Data
3
Inset Map
4
Bearing Information Windows
5
Barometric Minimum Descent
Altitude
6
FLIGHT PLAN Window
7
Selected Course
8
Vertical Deviation Indicator
9
Marker Beacon Annunciation
10
VNV Target Altitude
5
1
6
7
4
8
3
2
10
9
