GE MEDICAL SYSTEMS
DIRECTION 2317229, REVISION 3 LOGIQ™ 180 BASIC SERVICE MANUAL
7 - 6 Section 7-2 - Power On Diagnostics
CPU Board Tests (cont’d.,)
Erase Flash memory
When this option is run all the images stored in the flash assy is erased.
Main Menu
This option is used to return to the main menu.
Quit
This option is used to come out of the diagnostic and enter the application mode.
7-2-3 DSC Board Tests
When this Option is selected following menu appears
All Tests
This option is used to run all tests in the menu.
Image Memory Test
The image memory is tested in the same way as the memories on the CPU board.
Cine Memory Test
All the Cine Frames have been tested one by one by writing 4 test patterns and then reading the same.
Main Menu
This option is used to return to the main menu.
Quit
This option is used to come out of the diagnostic and enter the application mode.
Figure 7-47 DSC Board Tests
1.) ALL TESTS
2.) IMAGE MEMORY TEST
3.) CINE MEMORY TEST
P. MAIN MENU
Q. QUIT
ENTER THE CHOICE:_
DSC Tests
