GE MEDICAL SYSTEMS
DIRECTION 2317229, REVISION 3 LOGIQ™ 180 BASIC SERVICE MANUAL
Chapter 3 Installation 3 - 1
Chapter 3
Installation
Section 3-1
Overview
3-1-1 Purpose of Chapter 3
This chapter contains information needed to install the unit. Included are references to a procedure that
describes how to receive and unpack the equipment and how to file a damage or loss claim.
How to prepare the facility and unit of the actual installation, and how to check and test the unit, probes,
and external peripherals for electrical safety are included in this procedure. Also included in this section
are guidelines for transporting the unit to a new site.
3-1-2 Contents IN chapter 3
3-1-3 Average Installation Time
Table 3-14 Contents in Chapter 3
Section Description Page Number
3-1 Overview
3-1
3-2 Receiving and Unpacking the Equipment
3-4
3-3 Preparing for Installation
3-9
3-4 Assembling LOGIQ™ 180
3-9
3-5 Completing the Installation
3-10
3-6 System Configuration
3-18
3-7 Paperwork
3-27
Table 3-15 Average Installation Time
Description Average Installation Time Comments
Unpacking the scanner 20 Minutes
Scanner wo/options 40 Minutes Dependant on the configuration that is required
