GE MEDICAL SYSTEMS
DIRECTION 2317229, REVISION 3 LOGIQ™ 180 BASIC SERVICE MANUAL
9 - 14 Section 9-1 - Overview
9-1-10 Cables
Table 9-32 Cables
Item Part Name Part No. Description Qty FRU
901 Cable Assy Set 2347341
Panda Cable
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 16, 17, 18,
19, 20, 21.
Cable assy
2, 3, 5, 10, 11, 12, 13, 14, 15, 17, 19, 20, 21, 22, 61,
62, 63, 64, 65 and Power Cable assy
11
Panda Cable 1 2329701
Cable Assembly for power distributor to DSC
Assembly
1
Panda Cable 2 2329702
Cable Assembly for power distributor to CPU
Assembly
1
Panda Cable 3 2329703 Cable Assembly for keyboard to Freeze Assembly 1
Panda Cable 4 2329704 Cable Assembly for keyboard to Freeze Assembly 1
Panda Cable 5 2329705 TGC-FEB interface 1
Panda Cable 6 2329706 CPU-DSC interface 1
Panda Cable 7 2329707 CPU-KBD interface 1
Panda Cable 8 2329708
Cable Assembly for Low voltage power supply to
power distributor Assembly
1
Panda Cable 9 2329709 CPU-Rear Panel Parallel port cable 1
Panda Cable 10 2329710 Cable Assembly for Keyboard to trackball Assembly 1
Panda Cable 11 2329711
Cable Assembly for Keyboard to relay board
Assembly
1
Panda Cable 12 2329712 KBD-Chassis (GDN) cable 1
Panda Cable 13 2329713
Cable Assembly for Low voltage power supply to
power distributor Assembly
1
Panda Cable 14 2330381
Cable Assembly for power distributor to FEB
Assembly
1
Panda Cable 16 2330383
Cable Assembly for power distributor to CPU
Assembly
1
Panda Cable 17 2330384
Cable Assembly for Low voltage power supply to
220-240VAC input Assembly
1
Panda Cable 18 2335414 Cable Assembly for FEB to FH1 (connect with FH2) 1
Panda Cable 19 2337330
Cable Assembly for High voltage power supply to FH2
(connect with FH1)
1
Panda Cable 20 2337331
Cable Assembly DH1 (connect with DH2) to DSC
Assembly
1
Panda Cable 21 2337332 DSC-CPU interface cable 1
Power Cable Assy 2169670 220-240VAC input (2A) 1
Cable Assy 3 2160462 isolation transformer internal cable 1
Cable Assy 2 2160461 isolation transformer internal cable 1
