3 - 20 Section 3-6 - System Configuration
3-6-1-3 Weight without Peripherals
The Weight of LOGIQ™ 180 without peripherals
3-6-2 Electrical Specifications
Electrical Specifications for LOGIQ™ 180 .
3-6-2-1 Power Supply
The Following Power Line requirement should be monitored one week before Installation. We
recommend that a Drantez model 605-3 Power line Monitor with options 101 to be used.
Table 3-4 Power supply
3-6-2-2 Facility Power Socket
A separate power outlet with a 5 amp circuit breaker for 220-240 VAC is recommended. The specific
power receptacle used depends on the country's power line standards.
This receptacle should have International Electro technical Commission (IEC) approval, or equivalent
Table 3-2 Weight of LOGIQ™ 180
Model Weight [kg] Weight [lbs]
LOGIQ™ 180 72.2 163.17
Table 3-3 Electrical Specifications for LOGIQ™ 180
GEMS P/N Voltage Tolerances Current Frequency
H41542LA 220-240 VAC ±10% 1.9-2.0 A Max. 50 Hz
H41542LB 220-240 VAC ±10% 1.9-2.0 A Max. 50 Hz
H41542LC 220-240 VAC ±10% 1.9-2.0 A Max. 50 Hz
H41542LD 220-240 VAC ±10% 1.9-2.0 A Max. 60 Hz
Parameter Limits
Voltage Range China, Europe, India, Korea
200-240VAC
± 10%
Power China, Europe, India, Korea MAX 450VA
Line Frequency All Applications
50/60Hz
± 2Hz
Power Transients
Less than 25% of nominal peak voltage for less than 1 millisecond for any type of transient,
including line frequency, synchronous, asynchronous or periodic transients
Decaying Oscillation
Less than 15% of Peak Voltage for less than 1 millisecond
