GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
Section 3-2 - Setup reminders 3 - 3
3-2-2 Setup warnings
• The system weighs approximately 85 kg (LOGIQ S8) / 97 kg (LOGIQ E8) without peripherals, two
people are required to unpack it.
• There are no operator serviceable components. To prevent shock, do not remove any covers or
panels. Should problems or malfunctions occur, unplug the power cord. Only qualified service
personnel should carry out servicing and troubleshooting.
DANGER
WHEN USING ANY TEST INSTRUMENT THAT IS CAPABLE OF OPENING THE
AC GROUND LINE (I.E., METER’S GROUND SWITCH IS OPEN), DON’T
TOUCH THE UNIT!
WARNINGWARNING
DO NOT PULL OR LIFT THE SYSTEM WITH THE FRONT HANDLE OF THE USER
INTERFACE (OPERATOR PANEL).
WARNINGWARNING
!! WARNING:
THE SYSTEM SHOULD NOT BE MOVED WITH THE OPERATOR CONTROL PANEL
EXTENDED. MOVE THE OPERATOR CONTROL PANEL TO IT’S CENTERED AND
LOCKED POSITION. REFER TO Section 8-2-3 "Returning/Shipping Probes and
Repair Parts" on page 8-4.
CAUTION
!! CAUTION:
TO PREVENT ELECTRICAL SHOCK, CONNECT THE UNIT TO A PROPERLY GROUNDED
POWER OUTLET. DO NOT USE A THREE TO TWO PRONG ADAPTER. THIS DEFEATS
SAFETY GROUNDING.
CAUTION
!! CAUTION:
DO NOT WEAR THE ESD WRIST STRAP WHEN YOU WORK ON LIVE CIRCUITS AND MORE
THAN 30 V PEAK IS PRESENT.
CAUTION
!! CAUTION:
DO NOT OPERATE THIS ULTRASOUND SYSTEM UNLESS ALL BOARD COVERS AND
FRAME PANELS ARE SECURELY IN PLACE. SYSTEM PERFORMANCE AND COOLING
REQUIRE THIS.
(When covers are removed, EMI may be present).
CAUTION
OPERATOR MANUAL(S)
THE USER MANUAL(S) SHOULD BE FULLY READ AND UNDERSTOOD BEFORE
OPERATING THE LOGIQ S8/LOGIQ E8 AND KEPT NEAR THE UNIT FOR QUICK
REFERENCE.
CAUTION
ACOUSTIC OUTPUT HAZARD
ALTHOUGH THE ULTRASOUND ENERGY TRANSMITTED FROM THE LOGIQ S8 PROBE IS
WITHIN AIUM/NEMA STANDARDS, AVOID UNNECESSARY EXPOSURE. ULTRASOUND
ENERGY CAN PRODUCE HEAT AND MECHANICAL DAMAGE.
