4 - 20 Section 4-3 - Functional Checks
4-3-8 B-Mode functional checks (continued)
Probe indications for use
the online Help or Chapter 11 of the appropriate version of the LOGIQ Totus Basic User Manual. 1-4-
1 "Label Location" on page 1-13.
Preparations
You may use a phantom (optional) when doing these tests.
1.) Connect one of the probes, to the scanner’s active probe connector.
- Section 3-5-6 "Connecting probes" on page 3-16 for info about connecting the probes.
- For available probes, Section 9-13 "Probes" on page 9-24.
2.) Turn ON the scanner. The B-Mode window is displayed (default mode).
3.) If needed, adjust the Brightness and Contrast setting on the monitor ( Section 6-2 "Monitor
Adjustments" on page 6-2).
4.) Press B-MODE on the Operator Panel to access B-Mode.
5.) These Image Controls are used to optimize the B-Mode picture:
- Use Gain and TGC controls to optimize the overall image together with the Power control.
- Use Depth to adjust the range to be imaged.
- Use Frequency (move to higher frequencies) or Frame rate (move to lower frame rate) to
increase resolution in image.
- Use Frequency (move to lower frequency) to increase penetration.
- Use the control to optimize imaging in the blood flow regions and make a cleaner, less noisy
image.
- Use Reject controls to reduce noise in the image.
Checks
• Check Width, Frame rate, Frequency. The results of these adjustments must be verified on the
B-Mode sector on the screen.
• Check Up/Down, Left/Right, B Color Maps and Cineloop. The results of these adjustments must be
verified on the B-Mode sector on the screen.
• Check Gain, TGC and Depth.
• Check B-Mode Soft Menu Controls.
• Check Compress, Contour, Reject and Tilt.
• Check Power and Dynamic Range.
WARNINGWARNING
ALWAYS USE THE MINIMUM POWER REQUIRED TO OBTAIN ACCEPTABLE IMAGES
IN ACCORDANCE WITH APPLICABLE GUIDELINES AND POLICIES.
