GE LOGIQ Totus User Manual

GE HealthCare CONFIDENTIAL
Direction 5936427, Rev. 1 LOGIQ Totus Basic Service Manual
4 - 24 Section 4-3 - Functional Checks
4-3-15 CW Doppler mode functional checks
For information on the Ultrasound system’s different modes, the Basic User Manual will familiarize you
with image optimization for B-Mode, M-Mode, Color Flow, and Doppler.
1.) Connect one of the probes to the scanner.
2.) Turn ON the scanner.
3.) The 2D Mode window is displayed (default mode).
4.) If needed, adjust the display’s Brightness and Contrast setting.
5.) Press CW to start Continuous Wave Doppler (CW).
6.) Use the Trackball to select the direction of interest in CW.

GE LOGIQ Totus Specifications

General

Brand	GE
Model	LOGIQ Totus
Category	Medical Equipment
Language	English
